8 Operation
Maschinenfabrik Reinhausen GmbH 2020204 3587317/21 ENTAPCON
®
Settings
Parameters
Current ...ing
<< < > >>
Mode
Absolute
Relative
Hysteresis
Delay time
Reaction
Absolute
0.0A
0.0%
0.0A
0.0s
Off
Absolute
0.0A
0.0%
0.0A
0.0s
Auto blockin...
Absolute
7.7A
110.0%
0.0A
0.0s
Auto blockin...
Absolute
10.0A
110.0%
0.0A
0.0s
Off
Home
Events
Information
Recorder
Settings
EN
CHANGE
REBOOT
admin 29.01.2020 15:45
Figure141: Current monitoring
1. Go to Settings > Parameters > Grid > Current monitoring.
2. Select the desired parameter.
3. Set the desired parameter.
4. Press the Accept button to save the modified parameter.
Mode
You can use this parameter to set which limit value you would like to use:
▪ Absolute: The device uses the absolute limit value in A/kA.
▪ Relative: The device uses the relative limit value in %, relative to the rated
current of current transformer.
Absolute
You can use this parameter to specify an absolute limit value in A (in relation
to the secondary value of the current transformer) or in kA (in relation to the
primary value of the current transformer).
Percentage
You can use this parameter to set the limit value relative to the rated current
of current transformer. With current measurements via the analog input, the
value is relative to the maximum value of the analog input (e.g. 100% =
20mA).
Hysteresis
You can use this parameter to set the hysteresis. You can use this to avoid
the unnecessary generation of messages if the measured value fluctuates
around a threshold value.
