8 Operation
Maschinenfabrik Reinhausen GmbH 2020206 3587317/21 ENTAPCON
®
If the measured value is higher than the upper limit (> or >>) or lower than
the lower limit (< or <<), the device issues an event message.
Settings
Parameter
Power monitoring
<< < > >>
S absolute
S hysteresis
S delay
S behavior
P absolute
P hysteresis
P delay
P behavior
Q absolute
0VA
100kVA
5s
0VA
100kVA
5s
10MVA
100kVA
5s
10MVA
100kVA
5s
Off
-10 MW
100 kW
Off
-10 MW
100 kW
Off
10MW
100 kW
Off
10MW
100 kW
5s
Off
0 Mvar
5s
Off
0 Mvar
5s
Off
10 Mvar
5s
Off
10 Mvar
Home
Events
Information
Recorder
Settings
EN
CHANGE
REBOOT
admin 03.02.2020 08:09
Figure142: Power monitoring
1. Go to Settings > Parameters > Grid > Power monitoring.
2. Select the desired parameter.
3. Set the desired parameter.
4. Press the Accept button to save the modified parameter.
Absolute
You can use this parameter to specify a limit value.
Hysteresis
You can use this parameter to set the hysteresis. You can use this to avoid
the unnecessary generation of messages if the measured value fluctuates
around a threshold value.
Delay time
You can use this parameter to set the delay time in order to delay the issuing
of the event message.
Reaction
You can use this parameter to set the behavior of the device if the measured
value is higher than the upper limit (> or >>) or lower than the lower limit (<
or <<). You can select the following options:
Setting Behavior
Off No reaction.
Auto blocking Automatic regulation is blocked.
You can continue to perform tap-change operations in
manual mode.
