Function Result = Input 1 + Input 2 + Offset
If the REAL32 range of numbers is exceeded, the
Overflow output becomes TRUE.
Initial state All inputs and outputs are zero or FALSE.
Table109: Analog addition function module
8.30.1.3.17 Analog subtraction
Description SUB, analog subtraction
Inputs Input 1 (REAL32)
Input 2 (REAL32)
Outputs Result (REAL32)
Overflow (BOOL)
Parameter Offset (REAL32), -1,000,000...+1,000,000; default = 0
Function Result = Input 1 - Input 2 – Offset
If the REAL32 range of numbers is exceeded, the
Overflow output becomes TRUE.
Initial state All inputs and outputs are zero or FALSE.
Table110: Analog subtraction function module
8.30.1.3.18 Rising edge
Description RTRG, rising edge trigger
Inputs Input (BOOL)
Outputs Output (BOOL)
Parameter -
Function When the input changes from FALSE to TRUE, the
output becomes TRUE for one cycle of the function
group and then changes back to FALSE.
Initial state All inputs and outputs are FALSE.
Table111: Rising edge function module
8.30.1.3.19 Falling edge
Description FTRG, falling edge trigger
Inputs Input (BOOL)
Outputs Output (BOOL)
Parameter -
Function When the input changes from TRUE to FALSE, the
output becomes TRUE for one cycle of the function
group and then changes back to FALSE.
Initial state All inputs and outputs are FALSE.
Table112: Falling edge function module
