8 Operation
Maschinenfabrik Reinhausen GmbH 2020268 3587317/21 ENTAPCON
®
Function Output is calculated using the following formula:
Output = Min Out + (Max Out - Min Out) x
(Input – Min In) / (Max In – Min In)
Output is set to 0 and Error = TRUE when:
▪ Input is not within the parameters Min In and Max In
▪ Min In is greater than Max In
▪ Min Out is greater than Max Out
▪ Max In is the same size as Min In (division by zero)
Initial state All inputs and outputs are FALSE.
Table114: Scaling function module
8.30.1.3.22 Bridge
Designation BRDG, Bridge
Inputs Analog Input (REAL32)
Digital Input (BOOL)
Outputs Analog Output (REAL32)
Digital Output (BOOL)
Parameter -
Function Copies the value of Analog Input to Analog Output and
Digital Input to Digital Output.
Initial state All inputs and outputs are zero or FALSE.
Table115: Bridge function module
8.30.1.3.23 RTOI
Description RTOI, Real-to-Integer conversion
Inputs Analog Input (REAL32)
Outputs Analog Output (SINT32)
Parameter -
Function Copies the value of Analog Input to Analog Output and
converts REAL32 to SINT32.
Initial state All inputs and outputs are zero.
Table116: RTOI function module
8.30.1.3.24 ITOR
Description ITOR, Integer-to-real conversion
Inputs UINT32 (UINT32)
SINT32 (SINT32)
Outputs Output U (REAL32)
Output S (REAL32)
