11 Event messages
Maschinenfabrik Reinhausen GmbH 2020 2813587317/21 EN TAPCON
®
No. Name Description Remedy
16 Limit value P>> The limit value for active power P>> has
been exceeded.
Check the current operating conditions of
the transformer and the set P>> parame-
ters.
17 Limit value Q< Value has fallen below the limit value for
reactive power Q<.
Check the current operating conditions of
the transformer and the set Q< parame-
ters.
18 Limit value Q<< Value has fallen below the limit value for
reactive power Q<<.
Check the current operating conditions of
the transformer and the set Q<< parame-
ters.
19 Limit value Q> The limit value for reactive power Q> has
been exceeded.
Check the current operating conditions of
the transformer and the set Q> parame-
ters.
20 Limit value Q>> The limit value for reactive power Q>>
has been exceeded.
Check the current operating conditions of
the transformer and the set Q>> parame-
ters.
21 Limit value cos φ < Value has fallen below the limit value for
power factor cos f<.
Check the current operating conditions of
the transformer and the set parameters
cos f<.
22 Limit value cos f << Value has fallen below the limit value for
power factor cos f<<.
Check the current operating conditions of
the transformer and the set cos f<< pa-
rameters.
23 Limit value Pos< Value has reached or fallen below the
limit value for tap position Pos<.
Check the current operating conditions of
the transformer and the set Pos< param-
eters.
24 Limit value Pos> Value has reached or exceeded the limit
value for tap position Pos>.
Check the current operating conditions of
the transformer and the set Pos> param-
eters.
25 Function monitoring The measured voltage is outside of the
bandwidth.
Check the current operating conditions of
the transformer and the set bandwidth.
26 Switching direction con-
trol
The target tap position has not been
reached.
Check the RAISE/LOWER contact con-
nections and the functionality of the tap-
changer control.
27 Lower bandwidth limit
value
Value has fallen below the lower band-
width limit value.
The bandwidth is set too low. Check the
parameter.
28 Upper bandwidth limit
value
Value has exceeded the upper band-
width limit value.
The bandwidth is set too high. Check the
parameter.
29 Switching interval moni-
toring: Total tap-change
operations
The maximum number of total tap-
change operations has been exceeded.
Check the set number of total tap-
change operations and the current oper-
ating conditions of the affected network
segment.
30 Switching interval moni-
toring: Lower tap-change
operations
The maximum number of LOWER tap-
change operations has been exceeded.
Check the set number of LOWER tap-
change operations and the current oper-
ating conditions of the affected grid sec-
tion.
31 Switching interval moni-
toring: Raise tap-change
operations
The maximum number of RAISE tap-
change operations has been exceeded.
Check the set number of RAISE tap-
change operations and the current oper-
ating conditions of the affected grid seg-
ment.
