11 Event messages
Maschinenfabrik Reinhausen GmbH 2020284 3587317/21 ENTAPCON
®
No. Name Description Remedy
156 Motor protective switch Motor protective switch triggered. Follow the operating instructions for the
motor-drive unit.
157 Calculation of active-
power dependent de-
sired value
The active-power dependent desired
value cannot be calculated.
The active power needed to calculate the
desired value cannot be determined.
Check the measurement transformers
and their wiring.
158 Resistor contact series
calibration
The resistor contact series calibration
has not yet been performed or has failed.
Perform the resistor contact series cali-
bration.
176 Tap position analog input Measured value is outside permissible
range of analog input.
Check the signal source and wiring of
the analog input.
177 Desired value for analog
input
Measured value is outside permissible
range of analog input.
Check the signal source and wiring of
the analog input.
178 Desired value for analog
output
The value cannot be output via the ana-
log output.
Check the parameter settings and the
wiring of the analog output.
179 Voltage analog output The value cannot be output via the ana-
log output.
Check the parameter settings and the
wiring of the analog output.
180 Current analog output The value cannot be output via the ana-
log output.
Check the parameter settings and the
wiring of the analog output.
181 Active current analog
output
The value cannot be output via the ana-
log output.
Check the parameter settings and the
wiring of the analog output.
182 Reactive current analog
output
The value cannot be output via the ana-
log output.
Check the parameter settings and the
wiring of the analog output.
183 Active power analog out-
put
The value cannot be output via the ana-
log output.
Check the parameter settings and the
wiring of the analog output.
184 Reactive power analog
output
The value cannot be output via the ana-
log output.
Check the parameter settings and the
wiring of the analog output.
185 Apparent power analog
output
The value cannot be output via the ana-
log output.
Check the parameter settings and the
wiring of the analog output.
186 Tap position analog out-
put
The value cannot be output via the ana-
log output.
Check the parameter settings and the
wiring of the analog output.
241 CAN bus node is missing There is a problem communicating with a
TAPCON® in the parallel operation
group.
CAN bus communication not correctly
configured. Check wiring as per connec-
tion diagram. Use CAN bus address ≠0.
Assign a separate CAN bus address to
each TAPCON®.
242 CAN bus node is missing There is no CAN bus communication
with at least one further TAPCON®.
CAN bus communication not correctly
configured. Check wiring as per connec-
tion diagram. Use CAN bus address ≠0.
Assign a separate CAN bus address to
each TAPCON®.
301 Generic SCADA com-
mand 1
The generic SCADA command 1 has
been received.
-
302 Generic SCADA com-
mand 2
The generic SCADA command 2 has
been received.
-
303 Generic SCADA com-
mand 3
The generic SCADA command 3 has
been received.
-
