15 Technical data
Maschinenfabrik Reinhausen GmbH 2020 3253587317/21 EN TAPCON
®
IEC 61000-4-5 Immunity to impulse voltages (surge)
▪ AC power supply: 4 kV CM, 2 kV DM
▪ DC power supply: 2 kV CM, 1 kV DM
▪ Measurement (UI1/3): 4 kV CM, 2 kV DM
▪ Digital I/O: 2 kV CM, 1 kV DM
▪ Analog I/O, shielding on both sides: 2 kV CM
▪ Communication interfaces, shielding on both sides: 2
kV CM
IEC 61000-4-6 Immunity to conducted disturbances, induced by high-fre-
quency fields
▪ 10 V, 150 kHz...80 MHz, 80% AM
IEC 61000-4-8 Immunity to power frequency magnetic fields
▪ 100 A/m, 50/60 Hz, continuously
▪ 1000 A/m, 50/60 Hz, for 1 s
IEC 61000-4-11
IEC 61000-4-29
Immunity to drops in voltage, short interruptions, and volt-
age fluctuations
▪ 40% U
N
for 300 ms
▪ 0% U
N
for 100 ms
Table150: Immunity in accordance with IEC 61000-6-2
CISPR 11 (EN 55011) Industrial, scientific and medical equipment - Radio-fre-
quency disturbance characteristics - Limits and methods
of measurement: Class A
CISPR 16-2-1 Procedure for measuring high-frequency emitted interfer-
ence (radio interference) and immunity - measurement of
conducted emitted interference: Class A
CISPR 16-2-3 Procedure for measuring high-frequency emitted interfer-
ence (radio interference) and immunity - measurement of
radiated emitted interference: Class A
CISPR 22 (EN 55022) Information technology equipment - Radio disturbance
characteristics - Limits and methods of measurement:
Class A
Table151: Emitted interference in accordance with IEC 61000-6-4
Environmental durability tests
IEC60529 With OT1205: Degree of protection IP52 for the front,
IP20 for the rear
Without OT1205: IP20
IEC 60068-2-1 Dry cold - 25 °C / 96 hours
IEC 60068-2-2 Dry heat 70 °C / 96 hours
IEC 60068-2-78 Constant moist heat
+ 40 °C / 93% / 4 days, no dew
