9 Troubleshooting VJ-1604 Maintenance Manual
Rev.-05 9-38
11 6. Main board assembly
may be defective.
Replace MAIN board
assembly.
"4.4.7
Replacing
MAIN
Board" p.4-
49
7. Power board
assembly may be
defective.
Replace the power board
assembly.
"4.4.2
Replacing
Power Board
Assembly"
p.4-41
12 Ink cartridge cannot
be detected even if
installed.
1. Are the following
self-diagnosis
functions detected as
normal when
checked with
specified cartridge
securely inserted?
• Detection of
presence of ink from
"Ctrl 2: Sensor" ->
"Sen.3: etc" -> "12:
Ink END"
• Detection of
presence of cartridge
from "Ctrl 2: Sensor"
-> "Sen.3: etc" ->
"11: Ink NOT
KCMY"
• Follow the steps for the
message "[KCMY] No
Cartridge".
• After adjustment/
replacement, execute
initial ink charge from
"Update 1: Head Rank"
of self-diagnosis
function.
"(1) Head
Rank" p.5-56
2. Is specified cartridge
status detected as
normal when
checked through
"Ctrl 2: Sensor" ->
"Sen.3: etc" -> "7-10:
[KCMY]Ink ID" of
self-diagnosis
function with
specified cartridge
securely inserted?
• Follow the steps for the
message "Insert
specified cartridge".
• After adjustment/
replacement, execute
initial ink charge from
"Update 1: Head Rank"
of self-diagnosis
function.
"(1) Head
Rank" p.5-56
Table 9-7 Symptoms, Check Items and Actions for Initial Operation Problems (Continued)
No. Symptom Check item Action Reference
