VJ-1604  Maintenance Manual 9 Troubleshooting
9-39 Rev.-05
13 Operation panel
accepts no inputs.
1. Is operation panel
cover broken or
contaminated?
Replace operation panel
cover.
-
2. Check panel cable
connectors at
operation panel unit
assembly side and
MAIN board
assembly side.
• Is panel cable
inserted obliquely?
• Is it locked securely?
Reconnect following
connectors.
• Main board
assembly: J5
• Operation panel unit
assembly: J1
"4.4.7
Replacing
MAIN
Board" p.4-
49
3. Operation panel unit
assembly may be
damaged.
Replace panel unit
assembly.
"4.3.1
Replacing
Panel Unit"
p.4-30
4. Main board assembly
may be
malfunctioning.
Replace MAIN board
assembly.
"4.4.7
Replacing
MAIN
Board" p.4-
49
14 Machine prints
nothing though it
receives data.
1. Refer to "9.3.5
Online Function
Problem".
- "9.3.5
Online
Function
Problems"
p.9-64
Table 9-7 Symptoms, Check Items and Actions for Initial Operation Problems (Continued)
No. Symptom Check item Action Reference
