17 Specifications
192 SRM-3006 Narda
17.2 Three axis E-field antenna 3501/03
17.2.1 Characteristics
Frequency range 27 MHz – 3 GHz
The correction factors determined individually
during calibration are stored in an EEPROM and
are applied automatically when used in conjunction
with the SRM-3006 basic unit.
Antenna type E-field
Sensor type Three axis design with scanned axes
Dynamic range
1)
1) Typical measurement dynamic range for 10 dB signal to noise ratio (RBW = 1 kHz); 800 MHz
to 1.8 GHz
0.2 mV/m – 200 V/m
CW damage level 435 V/m or 50 mW/cm
2
Intrinsic noise display in
conjunction with the SRM-3006
basic unit (separate
measurement of a single
axis)
2)
2) Typical values
• 25 µV/m at 900 MHz with 1 kHz resolution
bandwidth (RBW)
• 40 µV/m at 2.1 GHz with 1 kHz resolution
bandwidth (RBW)
Intrinsic noise display in
conjunction with the SRM-3006
basic unit (for isotropic result)
2)
• 40 µV/m at 900 MHz with 1 kHz resolution
bandwidth (RBW)
• 70 µV/m at 2.1 GHz with 1 kHz resolution
bandwidth (RBW)
Measurement range limit
(for single CW signal)
• 300 V/m
• 1000 V/m for f = 110 MHz
Max. measurement range (in
conjunction with the SRM-3006
basic unit)
2)
200 V/m (without restrictions for total span of
27 MHz to 3 GHz)
RF connector N connector, 50 Ω
