3 Connecting Up and Starting to Use the Device
Narda SRM-3006 27
3.2.4 Device side panel with external connectors
3.3 Power supply
The power supply is normally taken from the rechargeable battery pack
provided. It is also possible to use the AC adapter / charger supplied with
the device as a power source.
No. Element Function / Description
1 Earphone socket For connecting an earphone for listening to saved
voice comments.
2 Optical connector For connecting optical cables for on-site device
communications
3 USB, Mini-B type For connection to a computer (PC).
4 Charging socket For connecting to an external AC adapter / charger
(nominal voltage: 9 V)
1234
