4.3.2 The lower status bar
The lower status bar gives information about the current measurement. The
contents of the display may vary, depending on the operating mode.
Figure 9: Lower status bar
Table 4: Lower status bar elements
Element Description
MR Measurement range.
RBW Resolution bandwidth.
Others Field strengths outside the selected services.
Sweep Time Duration of each measurement cycle.
Progress Measurement progress (checks the progress of processor-
intensive measurements until the first results are displayed
on the screen)
No. of Runs Number of measurements made since the measurement
was last started.
AVG Number of measurements used to form the average or time
for average formation.
