NARDA SRM-3006 - Single Axis E-Field Antenna 3531;01; Characteristics; Uncertainty

17 Specifications
Narda SRM-3006 199
Calibration
17.5 Single axis E-field antenna 3531/01
17.5.1 Characteristics
1 Typical measurement dynamic range for 10 dB signal to noise ratio (RBW = 1 kHz);
100 MHz – 2.2 GHz
2 Typical values
17.5.2 Uncertainty
1 Typical value k = 2 (K= extrapolation or correction factor for determining the assessment value)
+15 °C to +30 °C
Calibration 178 reference points
The SRM-3006 basic unit applies linear
interpolation between reference points
Recommended calibration
interval
24 months
Frequency range 27 MHz – 3 GHz
Antenna type E-Field
Sensor type Single axis passive wide band dipole
Dynamic range
1)
60 µV/m to160 V/m
CW damage level > 300 V/m or 25 mW/cm
2
Intrinsic noise display in
conjunction with the SRM-3006
basic unit
2)
20 µV/m from 100 MHz to 2.2 GHz with 1 kHz RBW
Measurement range limit 160 V/m
RF connector N connector, 50 Ω
Extended measurement
uncertainty
1)
(in conjunction with SRM-3006
basic unit and 1.5 m RF cable)
Frequency range Single axis
measurement
26 – 300 MHz 2.1 dB
> 300 – 433 MHz 2.4 dB
> 433 – 1600 MHz 2.2 dB
> 1600 – 3000 MHz 1.9 dB
Calibration uncertainty < 1.5 dB
