7 Safety Evaluation Mode
98 SRM-3006 Narda
Setting the RBW manually for the entire table
You can also enter the resolution bandwidth manually:
1. Press the RBW softkey.
2. Use the rotary control to highlight the desired value.
(The largest value displayed is the only largest possible value of all
services shown.)
3. Press the OK key.
Note: Finer resolution normally means slower measurement speed.
Regardless of the selected value, the narrowest resolution bandwidth is
limited by the narrowest service:
Setting the RBW separately for each service
Note: Separate RBWs cannot be selected unless Others = OFF.
The value selected manually on the device applies to the entire table. You
can also enter the resolution bandwidth for each service separately using
the PC software. Refer to the online Help function of the PC software for
information on how to do this.
Tip: More information about the RBW is found in the Glossary
on page 219.
7.2.5 Setting the measurement range (Meas. Range)
Safety Evaluation • Meas. Range
⇒ See Setting the measurement range (Meas. Range) on page 72.
7.2.6 Selecting the result type (Result Type)
Safety Evaluation • Result Type
⇒ See Selecting the result type (Result Type) on page 75.
RBW
Fspan narrowest service()
4
----------------------------------------------------------------------------
=
