5 The Main Menu
64 SRM-3006 Narda
The example below shows the parameters for the GSM-900 service. The
corresponding entries in the service table are found in column 3 of Table 17
(the example values are shown in bold type).
5.3 The memory menu
Main Menu • Memory
The following functions are contained in the Memory menu:
• Display data sets
• Display saved screenshots
• Conditional saving
• Timer controlled saving
• Set comment function
⇒ You can find detailed information about all these functions in chapter 13
Measurement Data Memory on page 157.
Example: GSM-900
Downlink: 935.2 – 960 MHz
Channel number: 1 – 124
Channel width: 200 kHz
–> without gap
–> all channels have the same width
Table 17: Description of Create Service Table list
Item Description Entries for the
example GSM-900P
First Service Start Frequency Starting frequency for the service 935.3
(center frequency of
935.2 – 935.4 MHz
First Service Channel Number First channel number in the service 1
Channel Step Width Channel bandwidth 200 kHz
Service Bandwidth Service bandwidth 200 kHz
Number of Services Number of services 124
Preferred RBW Preferred resolution bandwidth 50 kHz
(200 kHz/4)
