17 Specifications
182 SRM-3006 Narda
17.1 SRM-3006
17.1.1 RF features
If no different Information is made the stated specifications are effective only
in a temperature range from 20 °C to 26 °C and in a relative humidity range
from 25% to 75%. Before the specifications can be checked, the device
must be powered on for at least 30 minutes.
Frequency
Frequency Range 9 kHz to 6 GHz
Modes • Spectrum Analysis
• Safety Evaluation
• Level Recorder
•Scope
Resolution bandwidth (RBW) See specifications for each mode
Phase noise (SSB) 10 kHz carrier spacing < - 70 dBc (RBW =1 Hz)
300 kHz carrier spacing < - 100 dBc (RBW = 1 Hz)
Reference frequency Initial deviation < 1.5 ppm
Aging < 5 ppm over 15 years
Thermal drift < 1.5 ppm (within
specified operating
temperature range)
