9 Level Recorder Mode
122 SRM-3006 Narda
The maximum values are also shown in addition to the actual or mean
values:
To select a detector type:
1. Press the Result Type softkey.
2. Use the rotary control to select the desired result type and then press the
OK key to make the setting.
9.4 Selecting an axis mode (Axis)
Level Recorder • Axis
⇒ See Selecting an axis mode on page 84.
9.5 Using noise suppression (Noise Thresh.)
Level Recorder • Meas. Range • Noise Thresh. / Noise Suppr.
⇒ See Noise suppression (Noise Thresh.) on page 90.
Table 30: Values displayed in Level Recorder mode
Type Explanation
Peak Displays the instantaneous measured value.
Note: The peak value display (Peak) is held for 480 ms. The value
displayed therefore corresponds to the highest level
measured within the last 480 ms. This means that the
numerical display is more stable and the graphical display is
smoothed.
Peak Max Displays the maximum value that has occurred since the
measurement started.
RMS The measured values are averaged over a defined period of time.
The resulting value is displayed. A bar indicates the progress of the
measurement until the averaging time is reached. When this time is
reached (complete bar), the instrument refreshes the resulting value
using the new measurement results and discards the oldest results
so that the averaging is progressive over time. The averaging time is
defined in the CONF menu.
RMS Max Displays the maximum value of the averaged values that has
occurred since the measurement started.
