NARDA SRM-3006 - Antennas; Options

17 Specifications
Narda SRM-3006 203
17.7 Single axis H-field antenna 3551/02
17.7.1 Characteristics
1 Typical measurement dynamic range for 10 dB signal to noise radio (RBW = 1 kHz); for
frequencies > 10 MHz
2 Typical values
17.7.2 Uncertainty
1 Typical value k = 2 (K= extrapolation or correction factor for determining the assessment value);
+15 °C to +30 °C
17.7.3 General specifications
Frequency range 9 kHz – 300 MHz
The correction factors determined individually
during calibration are stored in an EEPROM and
are applied automatically when used in conjunction
with the SRM-3006 basic unit.
Antenna type H-field
Sensor type Single axis active magnetic loop
Dynamic range
1)
0.4 µA/m – 71 mA/m
CW damage level > 2.65 A/m above 1 MHz
Intrinsic noise display in
conjunction with the SRM-3006
basic unit
2)
0.12 µA/m for each frequency > 10 MHz with 1 kHz
resolution bandwidth RBW
Measurement range limit
(for single CW signal)
2)
100 mA/m
RF connector N connector, 50 Ω
Extended measurement
uncertainty
1)
(in conjunction with SRM-3006
basic unit and 1.5 m RF cable)
Frequency range Single axis
measurement
0.1 – 300 MHz 2.0 dB
Calibration uncertainty < 1.2 dB
Operating temperature range -10 °C to +50 °C (same as SRM-3006 basic unit)
Air humidity < 29 g/m
3
(< 93 % at +30 °C)
