3 Connecting Up and Starting to Use the Device
26 SRM-3006 Narda
3.2.2 Device side panel with antenna / cable
connectors
3.2.3 Device side panel with battery compartment
No. Element Function / Description
1 Multi-pin connector 12-pole socket for connecting the control cable (for
automatic recognition of antenna and cable when
using a Narda antenna or Narda cable).
2 N connector Antenna connecting socket
12
No. Element Function / Description
1 Battery compartment
with lid and fixing
screw
Holds the rechargeable batteries.
1
