CODE CALLING ACCESS
– 152 –
A2148-10
CODE CALLING ACCESS
PROGRAMMING
DESCRIPTION DATA
Assign the interface trunk (COT card and
DK card) to the required LEN.
NOTE 1: The DK card number must be as-
signed to the first LEN (Level 0)
and the third LEN (Level 2) of
each LT slot.
(1)
(2)
000-763: LEN
D000-D255: COT Card No.
E800-E831: DK Card No.
For PIM0/1: E800-E807
For PIM2/3: E808-E815
For PIM4/5: E816-E823
For PIM6/7: E824-E831
NOTE 2: Circuit No. 3 of E831 is used
for built-in External Equip-
ment Interface of MP card by
setting CM44.
Assign the trunk data to the trunk number. •
(1)
(2)
Y=0 Trunk Route Allocation
000-255: Trunk No.
00-63: Trunk Route No.
Dedicated route number for this service
should be assigned.
•
(1)
(2)
Y=01 Tenant Allocation
000-255: Trunk No.
00, 01 -63: Tenant No.
Assign the route data to the trunk route
specified by CM30 Y=00.
•
(1)
(2)
Y=00 Kind of Route
00-63: Trunk Route No.
05
•
(1)
(2)
Y=01 Type of Signal to be sent out
00-63: Trunk Route No.
2: DP
4: DTMF
•
(1)
(2)
Y=08 Dial Pulse Sending
00-63: Trunk Route No.
3 : To send
CM30
CM35
START
CM10
A
To Next Page
