AUTOMATIC INTERCOM-D
term
– 66 –
A2066-10
AUTOMATIC INTERCOM-D
term
PROGRAMMING
DESCRIPTION DATA
Assign an Automatic Intercom number to
the Virtual LEN. The Automatic Intercom
stations are paired as shown below.
GROUP No. INTERCOM NUMBER
00 A000, A100
01 A001, A101
31 A031, A131
(1)
(2)
000-255: Virtual LEN
A000-A031
A100-A131
(Automatic Intercom No.)
AX YY
X : 0/1 to be made one pair
YY: 00-31: Automatic Intercom
Group No.
NOTE: The maximum number of Automatic Intercom paired stations per system is 32 (16
Automatic Intercoms).
Assign each Automatic Intercom station. •
(1)
(2)
Y=03
A000-A031, A100-A131: Automatic In-
tercom No. assigned by CM11
05: Automatic Intercom
Specify the busy indication on the Auto-
matic Intercom LED when the other D
term
of the same Automatic Intercom Group is
busy.
•
(1)
(2)
Y=11
X-XXXXXXXX: My Line No.
0 : Allowed
1 : Restricted
CM12
CM13
CM11
A
START
~
~
To Next Page
