NEC NEAX 2000 Programming Manual

TIE LINE CONNECTION WITH PAD CONTROL
– 512 –
A2512-10
TIE LINE CONNECTION WITH PAD CONTROL
PROGRAMMING
DESCRIPTION DATA
Specify the value of the Tie Line Pad. •
(1)
(2)
Y=19
00-63: Trunk Route No.
0-3 : Programmable PAD (See CM42)
4-7 : Fixed PAD
(See Table 1 or Table 2)
T/R: Transmit/Receive
+/–: Gain/Loss
START
CM35
A
Table 1 Fixed PAD for Australia
CONNECTION PATTERNS
(A-B)
PAD DATA OF B TRUNK
DATA=4 (T/R) DATA=5 (T/R) DATA=6 (T/R) DATA=7 (T/R)
Station-ODT 0/0 0/0 0/0
Tone-ODT 0/0 0/0 0/0
COT/LDT-ODT 0/0 –8/–8 –8/–8
ODT-ODT 0/0 –8/–8 –3/–3
DTI/BRT-ODT 0/0 –8/–8 –3/–3
Station-LDT 0/+6 0/+6 0/+6
Tone-LDT 0/+6 0/+6 0/+6
LDT-LDT 0/+6 –6/+6 –6/+6
ODT-LDT 0/+6 –6/+6 0/+6
DTI/BRT-COT/LDT 0/+6 –6/+6 0/+6
