INCOMING CENTRAL OFFICE CALL TO TIE LINE CONNECTION
– 278 –
A2270-10
INCOMING CENTRAL OFFICE CALL TO TIE LINE CONNEC-
TION
PROGRAMMING
DESCRIPTION DATA
Assign route number to C.O. trunks and
Tie Line trunks.
Assign the terminating system of the C.O.
trunks to ATTCON/DESKCON.
•
(1)
(2)
•
•
•
•
(1)
(2)
Y=00
000-255: Trunk No.
00-63: Trunk Route No.
Y=02 In Day Mode
Y=03 In Night Mode
Y=40 In Mode A
Y=41 In Mode B
000-255: Trunk No.
14: Termination to Attendant Console
Assign the route data to C.O. trunks and
Tie Line trunks.
•
(1)
(2)
•
(1)
(2)
Y=00 Kind of trunk route
00-63: Trunk Route No.
00: C.O. Line
04: Tie Line
Y=02 IC/OG
00-63: Trunk Route No.
1 : Incoming trunk
2 : Outgoing trunk
3 : Bothway trunk
Set 1 or 3 to C.O. Line, and 2 or 3 to Tie
Line.
•
(1)
(2)
•
(1)
(2)
Y=04 Answer Signal on Tie Line
00-63: Trunk Route No. of Tie Line
2: Answer Signal arrives from distant
office
Y=05 Release Signal
00-63: Trunk Route No.
0 : No Release Signal
1 : Release Signal arrives from dis-
tant office
Set 1 to Tie Line, and 0 or 1 to C.O. Line.
CM35
START
CM30
A
