HOT LINE-OUTSIDE
– 271 –
A2270-10
HOT LINE-OUTSIDE
PROGRAMMING
DESCRIPTION DATA
Assign the Hot Line to required stations. •
(1)
(2)
Y=03
X-XXXXXXXX: Station No.
04: Hot Line
Allocate the memory area for the Hot Line-
Outside call.
For example, to assign the 10 Hot Line-
Outside calls into No.100 through No.109
Memory Slots, 2nd data is “100010”. Ab-
breviated Codes are automatically as-
signed as shown below.
Ab
brev. Code
Memory Slot No. 100 00
Memory Slot No. 109 09
(1)
(2)
65: For Hot Line-Outside
XXX YYY
XXX: 000-299: Starting Memory Slot
No.
YYY: 001-100: Number of Memory
Slots required
CM71
START
CM12
A
To Next Page
