PUSHBUTTON TO ROTARY CONVERSION
– 396 –
A2382-10
PUSHBUTTON TO ROTARY CONVERSION
PROGRAMMING
For the assignment of DTMF Station, refer to “PUSHBUTTON CALLING”.
page 392
HARDWARE REQUIRED
DTMF Receiver (8RST card)
× n (as required)
n: Depending on the number of DTMF stations and traffic condition of the system.
DESCRIPTION DATA
Assign the type of signaling for Outgoing
and Bothway trunk routes to DP.
And, specify the DP Sender characteris-
tics to match the distant office.
•
(1)
(2)
Y=01
00-63: Trunk Route No.
2: DP-10PPS
3: DP-20PPS
•
(1)
(2)
Y=23 DP Sender Inter Digital Pause
00-63: Trunk Route No.
0 : 300 ms.
1 : 400 ms.
2 : 500 ms.
3 : 600 ms.
4 : 700 ms.
5 : 900 ms.
6 : 1100 ms.
7 : 800 ms.
•
(1)
(2)
Y=25 DP Sender Make Ratio
00-63: Trunk Route No.
0 : 39%
1 : 33%
•
(1)
(2)
Y=45 DP Sender Release Timing
00-63: Trunk Route No.
0 : 2 sec.
1 : 4 sec.
2 : 6 sec.
3 : 8 sec.
4 : 12 sec.
5 : 14 sec.
6 : 16 sec.
7 : 10 sec.
START
END
CM35
To Next Page
