SOFT KEY-D
term
– 441 –
A2437-10
To provide the Soft Keys for NEAX Mail AD-8 live recording, assign the following data.
HARDWARE REQUIRED
D
term
with Soft Keys and DLC card
DESCRIPTION DATA
Provide the Record key on the feature key
of the D
term
.
•
(1)
(2)
Y=00
My Line No. + + Key No.
F1091: Record
Assign the function of each Soft Key for
NEAX Mail AD-8 live recording.
NOTE: For the Pattern No. 3, the initial
Soft Key data for NEAX Mail AD-
8 live recording is assigned as
follows.
•
(1)
(2)
Y=00-03 Soft Key Pattern No. 0-3 as-
signed by CM12 Y=23
12 XX
XX: 00-15: Soft Key No.
00-03: Indicated on 1st display
04-07: Indicated on 2nd display
08-11: Indicated on 3rd display
12-15: Indicated on 4th display
F1092: Pause
F1093: Re-record
F1094: End
F1095: Erase
F1096: Address
F1097: Urgent Page
•
(1)
(2)
Y=10-13 Soft Key Pattern No. 0-3 as-
signed by CM12 Y=23
Same as CM9A Y=00-03
Characters (Max. 12 characters)
See APPENDIX B: CHARACTER
CODE TABLE.
CM9A
START
END
CM90
,
CM9A Y=03 CM9A
Y=13
Indication
1st Data 2nd Data
1200 F1096
(Address)
Addrs
1201 F1092 (Pause) Pause
1202 F1094 (End) End
1203 F5002 (Scroll) >>>>
1204 F1093
(Re-record)
ReRec
1205 F1095 (Erase) Erase
1206 F1017 (MIC) MIC
1207 F5002 (Scroll) >>>>
1208 F1097
(Urgent Page)
Urgnt
1209 NONE
1210 NONE
1211 F5002 (Scroll) >>>>
To Next Page
