NEC NEAX 2000 Programming Manual

TIE LINE CONNECTION WITH PAD CONTROL
– 514 –
A2512-10
HARDWARE REQUIRED
LDT/ODT card
DESCRIPTION DATA
END
B
CM42
Table 4 Programmable PAD for Australia
T/R: Transmit/Receive
+/–: Gain/Loss
PAD DATA OF
B TRUNK (T/R) [dB]
REMARKS
ODT LDT
00
15
00 0/0 0/+6
01 –3/–3 0/+6
02 –8/–8 –6/+6
03 –6/–6 0/0
04 0/0 0/+6
05 0/–6 0/0
06 –6/0 0/0
07 0/0 0/0
08
15
Not Used
PATTERNS
2ND DATA
~
~
Table 5 Programmable PAD for Other Countries
T/R: Transmit/Receive
+/–: Gain/Loss
PAD DATA OF B TRUNK (T/R) [dB]
REMARKS
ODT
(4W E&M)
ODT
(2W E&M)
COT/LDT DTI/BRT
00
15
00 0/0 0/0 0/0 0/0
01 0/0 0/0 0/0 –2/–2
02 0/0 0/0 0/0 –3/–3
03 –2/–2 –3/–3 –3/–3 0/–6
04 –3/–3 0/0 0/0 –3/–8
05 –12/–11 –6/–6 –6/–6 +3/–3
06 –16/–11 0/0 0/+5 –6/–6
07 –6/–6 0/0 +3/+3 –8/–8
08
15
Not Used
PATTERNS
2ND DATA
~
~
