XPS Unified Programmer’s Manual
7.2.1.64 GPIODigitalSet
Name
GPIODigitalSet – Sets one digital output.
Input tests
- Refer to section 7.1: “Input Tests Common to all XPS Functions”.
- GPIO name (DO): (-8)
- Hardware compatibility or XPS initialization in progress: (-22)
Description
Sets the value of the selected digital output (DO).
Prototype
int GPIODigitalSet(
int SocketID,
char * GPIOName,
unsigned short Mask,
unsigned short DigitalOutputValue
)
Input parameters
SocketID int Socket identifier gets by the
“TCP_ConnectToServer” function.
GPIOName char * Digital GPIO name (maximum size = 250).
Mask ushort Mask.
DigitalOutputValue ushort Digital output value.
Output parameters
None.
Return (In addition to the results of “Input Tests Common to all XPS
Functions”)
• 0: No error.
• -8: Wrong object type for this command.
• -22: Not allowed action.
111 EDH0373En1023 — 01/18
