Newport XPS-D Programmer's Manual

XPS Unified Programmer’s Manual
6.5.7 ZYGO Axis Status List
code
Status description
0
Success
0x0001
Reference signal present
0x0002
Reference PLL
0x0004
System OK
0x0008
Measure Signal present
0x0010
Position Reset Complete
0x0020
ADC Ready
0x0040
ADC Mux = 0
0x0100
External Sample Flag (SCLK0)
0x0200
Not used
0x0400
Not used
0x0800
Not used
0x1000
System Type ST0
0x2000
System Type ST1
0x4000
System Type ST2
0x8000
System Type ST3
The axis status register is read via Ethernet.
