XPS Unified Programmer’s Manual
7.2.1.375 XYPTExecution
Name
XYPTExecution – Executes a PT trajectory.
Input tests
- Refer to section 7.1: “Input Tests Common to all XPS Functions”.
- Checks trajectory file name length: (-3)
- Checks group type (must be a XY group): (-8)
- Checks input value (number of executions must >0): (-17)
- Checks group name: (-19)
- Group state must be "READY”: (-22)
- Checks backlash (must not be enabled): (-46)
- Checks BaseVelocity (stages.ini, must = 0): (-48)
- Checks trajectory file existence or file reading: (-61)
- Checks message queue: (-71)
- Not available in this configuration (PrecisionPlatform firmware only): (-24)
Description
This function executes a PT (Position Time) trajectory. The trajectory file must be
stored in the folder “\Admin\Public\Trajectory” of the XPS controller. If the trajectory
cannot be initialized (message queue or task error) then (-72) is returned.
Before a trajectory execution, it is recommended to check whether the trajectory is
within the positioner motion capabilities by using “XYPTVerification” and
“XYPTVerificationResultGet” functions.
During the trajectory execution, if a positioner reaches one of travel limits, the
trajectory execution will stop and the (-25) error is generated in the positioner errors.
NOTES
In case of (-33) error, (-25) error or (-44) error, the group state becomes
DISABLE. To help determine the error source, check the positioner errors, the
hardware status and the driver status.
This function can be used only with the XPS-Q Precision Platform controller.
Prototype
int XYPTExecution(
int SocketID,
char GroupName[250],
char FileName[250],
int ExecutionNumber
)
547 EDH0373En1023 — 01/18
