XPS Unified Programmer’s Manual
8.7 Positioner Driver Status List
Bit
code
DRV00x
DRV01
DRV02x
D6U
DRV03
DRVP1
0 a
Short-
circuit
Short-
circuit
Short-
circuit
1 b
Broken fuse Broken fuse Broken fuse
Voltage out
of range
2 c
Thermistor
fault
Thermistor
fault
Over
temperature
3 d
Initializatio
n error
Initializatio
n error
Initializatio
n error
Initialization
error
4 e
I²T I²T I²T
Dynamic
error
5 f
Current
limit
Current
limit
6 g
TG is
opened
No stage
connected
7 h
Inhibition
input
Inhibition
input
Inhibition
input
Inhibition
input
Inhibition
input
Inhibition
input
8 i
Driver in
fault
Driver in
fault
Driver in
fault
Driver in
fault
Driver in
fault
Driver in
fault
679 EDH0373En1023 — 01/18
