Newport XPS-D Programmer's Manual

XPS Unified Programmer’s Manual
XPS-RL or XPS-D Hardware:
Basic GPIO board:
• GPIO1.DI
• GPIO1.DO
• GPIO2.ADC1
• GPIO2.ADC2
• GPIO2.DAC1
• GPIO2.DAC2
Extended GPIO board:
• GPIO3.DI
• GPIO3.DO
• GPIO5.DI
• GPIO5.DO
• GPIO6.DI
• GPIO6.DO
• GPIO4.ADC1
• GPIO4.ADC2
• GPIO4.ADC3
• GPIO4.ADC4
• GPIO4.ADC5
• GPIO4.ADC6
• GPIO4.ADC7
• GPIO4.ADC8
• GPIO4.DAC1
• GPIO4.DAC2
• GPIO4.DAC3
• GPIO4.DAC4
• GPIO4.DAC5
• GPIO4.DAC6
• GPIO4.DAC7
• GPIO4.DAC8
ISRCorrectorTimePeriod
ISRCorrectorTimeUsage
ISRProfilerTimeUsage
ISRServitudesTimeUsage
CPUTotalLoadRatio
EDH0373En1023 — 01/18 674

Newport XPS-D Specifications

General

Brand	Newport
Model	XPS-D
Category	Controller
Language	English
