Scrub System 311Service Manual – CS7000
11. Reinstall the Scrub Deck by following the above steps in reverse order.
Service Note: When you reinstall the Scrub Deck:
• Make sure you reconnect the Scrub Motors to the correct Electrical Connectors in the wire harness as
follows:
– Left scrub motor - White/Orange wire
– Center scrub motor - Gray/Black wire
– Right scrub motor - Blue/Yellow wire
• Make sure the two Flange Bearings are installed in the machine frame through holes, and that the
Bushings and washers are installed correctly before installing the two M12-1.75x 35mm Screws.
• You may nd it easier to use a tapered punch or other suitable tool to align the Bushings, Flange
Bearings
and Deck Lift Arm Assembly with the through holes in the frame before you install the
M12-1.75x 35mm Screws.
