Solution System 336Service Manual – CS7000
8. Disconnect the Steering Sensor Electrical Connector.
9. Disconnect the additional wiring
running from the solution tank to
the engine (ground, starter, engine
interface, etc.).
10. Remove the Electrical Panel.
11. Remove the Main Machine Controller.
12. Disconnect any additional solution lines or electrical
connectors from the solution tank that may be
present if your machine is equipped with an extended
scrub system, high-pressure spray system or wash
hose kit.
Steering Sensor
Electrical Connector
Electrical
Panel
Main Machine
Controller
To Next Page
