Wheel System, Traction 432Service Manual – CS7000
16. Hook up a hoist to the lift strap and put a slight tension on the strap. Remove the rear wheel chock and
allow the assembly to roll backward and downward out of the machine controlling the movement by
lowering the hoist and blocking the wheel.
17. To separate the motor from the gear box, remove the attaching screws and pry apart.
18. Reassembly notes:
a. Be sure to apply anti-seize compound to the motor shaft splines and gearbox splines.
b. If installing a new gear box, be sure to ll it to the bottom of the ll plug with 80W90 oil when the
assembly is installed.. Holds 2.2L (.59 Gal) (Part number 56510411).
Apply Anti-seize
Fill Plug
