Wheel System, Traction 431Service Manual – CS7000
11. Remove the 2 inner gear box to frame bolts and loosen the remaining 4.
12. Lift the machine just enough to take weight off the gear box and remove the remaining 4 gear box to
frame bolts.
13. Attach a lifting strap around the drive motor. You will use the strap to guide and lower the assembly.
14. Slowly lift the machine up to allow the drive motor and gear box assembly to come out the bottom while
holding the motor assembly upright using the lifting strap.
15. Secure the machine safely on jack stands.
Remove 2
Loosen 4
To Next Page
