Control System 62Service Manual – CS7000
− EcoFlex switch: Turn ON EcoFlex LED
− High Pressure Pump switch: Turn ON
High Pressure LED
− Extended Scrub ON/OFF switch: Turn
ON Extended Scrub LED
◦ Other Functions
− Right Turn switch: Turn ON Right Turn
LED
− Left Turn switch: Turn ON Left Turn
LED
− Hazard switch: Turn ON LEFT and
Right Turn LEDS
− Headlights switch: Turn On Headlight
LED
− Horn switch: Turn ON Caution and
Warning LEDs
− Fast/Slow Select switch: Turn On
Rabbit/Turtle LED
• 16 or 17 Restore Defaults (Resets all
Conguration Menu selections and User Options
selections to default values)
– Are you sure? (One-touch scrub switch =
“Yes”. Solution switch= “No”.
– 17 or 18 Haram Captor
– 1 No (Use for all CS7000 models)
– 2 Yes (Use for special market Haram Captor
model to customize solution level processing
and scrub pressures)
• 18 UI Part Number (Used for the control panel
to display properly when the hopper is not
seated. “Late” control panels PN 56511559 have
a “hopper up” icon to be used with an updated
main machine controller software ID 56111560).
– 56511559 (Late Control Panel)
– 56509476 (Early Control Panel)
Note: An updated main machine
controller (Software ID 56111560)
was introduced around August
2015. It has some expanded
support for the service technician
in the “hidden” service menu.
There are no visible differences
in the new controller. You can
determine whether you have the
new controller by accessing the
Conguration Menu/Service
Menu/About to check the part
number and revision level.
