Printer Configuration
184 A29247-X6-X-6-7670
Connection details:
Electronic Switchbox If there is an electronic switchbox between server and printer in-
stalled, it can be necessary to enable this checkbox. But enable this
item only, if the switchbox rejects to switch the printer to another host.
Internally the 370-Channel board(s) will set in reset state, when they
are not used, but it takes more time to get them running, every time
the printer is enabled.
Unit This is the physical number of the I/O interface, starting with 0.
Example:
1st SCSI Controller or 370-Channel board has the number 0.
2nd SCSI Controller or 370-Channel board has the number 1.
For LPT printers you can select untits LPT1 to LPT3.
Address Address on the 370 Channel or the SCSI bus.
Address range: 00-FF (0-255) for 370-channel connection
00-0F (0-15) for SCSI connection
Hostname Tcp/ip-address or the hostname of the destination system.
Port Number The tcp/ip port number, which is expected by the receiving system.
Printqueue The name of the printqueue on the destination system.
Directory The directory on the destination system, where the data has to be
transfered.
User The username, which should be used for user ftp login.
Password The password, which should be used for ftp login.
