86
Chapter2 Reduced Resolution
F3SG-R
User’s Manual
System Operation and Functions
2-16-2. Factory Default Setting
The factory default setting is the Reduced Resolution Disable.
2-16-3. Setting with DIP Switch
The user cannot make any changes to this function by the DIP Switch.
2-16-4. Setting with Configuration Tool
Some settings of functions configurable with the Configuration Tool may increase risks.
Make sure the Responsible Person conduct a thorough risk assessment analysis before
managing and changing the settings. Unintended changes to the settings may cause a
person to go undetected, resulting in serious injury.
The user can make changes to the settings by the Configuration Tool.
*It is not possible to configure the Reduced Resolution function together with the Muting function. To
enable settings of the Reduced Resolution function, disable the Muting function.
In addition, setting parameters of the following functions are saved according to the states where the
Muting function is enabled and disabled, respectively. After changing the Muting function from Enable
to Disable or from Disable to Enable, also check the settings of these functions again.
Affected functions: External Device Monitoring (EDM), Start Interlock, Restart Interlock, Auxiliary
Output, Lamp Output
Make sure the Position 8 of the DIP Switch is set to Configuration Tool Enabled to activate the settings by the
Configuration Tool.
Refer to Safety Light Curtain Configuration Tool for Model F3SG (SD Manager 2) User’s Manual for more
information on setting this function by the Configuration Tool.
Function Name Factory Default Setting Available Parameters
Reduced Resolution Disable Enable*/Disable
Number of beams 1 1 to 3 beams in 1-beam increments
