103
F3SG-R
User’s Manual
Chapter2 Maintenance Information
System Operation and Functions
E
The user can make changes to the settings by the Configuration Tool.
2-24-5. Load Switching Frequency
The user can view the number of operations of the load connected to F3SG-RA. The number of load
operations can be used to understand the switching frequency of relays and contactors connected to
F3SG-RA.
It is possible to give an output signal to the auxiliary output or indicate with Lamp (F39-LP and F39-
BTLP, sold separately) when the number of operations exceeds the switching frequency threshold.
The excess load switching frequency information must be assigned to the output operation mode of
the auxiliary output or Lamp.
2-11. Auxiliary Output
2-21. Lamp
The user can make changes to the settings by the Configuration Tool.
2-24-6. Muting Statistics Information
This function calculates parameter data required for the muting system statistically based on the actual
measurement. Man-hour required for muting system construction can be reduced by using parameters
acquired from the statistical calculation.
Function Factory Default Setting Available Parameters
Power-on time threshold 30,000 h 30,000 to 1,000,000 h in 1-h increments/Disable
Function Factory Default Setting Available Parameters
Load switching frequency threhshold 100,000 times in 1-time increment 100,000 to 4,000,000 times in 1-time increments/
Disable

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
