Omron F3SG series User Manual

26
Chapter2 Scan Code Selection
F3SG-R
User’s Manual
System Operation and Functions
2-4. Scan Code Selection
2-4-1. Overview
The F3SG-RA has two scan codes (Code A and Code B). These scan codes have different internal
processing time. The use of different scan codes allows for placement of systems in close proximity
and in line with each other and minimize mutual interference.
The Scan Code Selection is not available for the F3SG-RE.
Refer to 4-1-4. Mutual Interference Prevention for how to mitigate mutual interference.
2-4-2. Factory Default Setting
The factory default setting is Code A.
Both the emitter and receiver units must be set to the same code.
2-4-3. Setting with DIP Switch
The user can select the scan code from Code A or Code B by the DIP Switch.
Refer to Chapter 3 Setting with DIP Switch for more information on setting this function by the DIP Switch.
2-4-4. Setting with Configuration Tool
The user cannot make any changes to the scan code by the Configuration Tool.
F3SG-RA Series X
F3SG-RE Series

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
