F3SG-R
User’s Manual
Chapter2 Auxiliary Output
System Operation and Functions
E
2-11-4. Setting with Configuration Tool
Some settings of functions configurable with the Configuration Tool may increase risks.
Make sure the Responsible Person conduct a thorough risk assessment analysis before
managing and changing the settings. Unintended changes to the settings may cause a
person to go undetected, resulting in serious injury.
The user can make changes to the settings by the Configuration Tool.
• Output operation mode
Information to be allocated to the auxiliary output
• Inverted signal output mode
Auxiliary output gives a inverted signal of the safety output.
• Output pattern
Pattern to send an output signal from the auxiliary output
The user can make changes to the settings by the Configuration Tool.
*1. Setting parameters of this function are saved according to the states where the Muting function is
enabled and disabled, respectively. After changing the Muting function from Enable to Disable or
from Disable to Enable, also check the settings of this function again.
Refer to  Considerations for enabling and disabling Muting function under 2-1. Combination of
Functions for more information.
Refer to 2-12. Muting for more information on settings of the Muting function.
*2. Refer to the table of Information (Output operation mode) assigned to auxiliary output below.
*3. Output signal is sent according to the patterns as shown in the output pattern chart below.
 Output pattern chart
Information (Output operation mode) assigned to auxiliary output
Function
Factory Default Setting
Available Parameters
Muting function enabled*1 Muting function disabled*1
Output operation mode Muting/Override information Safety output information *2
Inverted signal output Disable Enable Enable/Disable
Output pattern ON 1 time *3 Solid-ON Solid-ON/ON 1 time *3
Information Name
Description
(Auxiliary output is turned ON under the following condition)
Safety output information When Safety output is in the ON state.
Reset-input information When Reset/EDM/Override input is in the ON state
Interlock information Under Interlock state
Pre-reset Information Under Pre-reset state
Solid-ON
ON 1 time
1 s

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
