Omron F3SG series User Manual

27
F3SG-R
User’s Manual
Chapter2 PNP/NPN Selection
System Operation and Functions
E
2-5. PNP/NPN Selection
2-5-1. Overview
The F3SG-RA offers PNP/NPN selection for the user to select the polarity of the inputs and outputs of
the receiver between PNP and NPN.
When the system is set to the NPN type, the “NPN” indicator is illuminated.
The PNP/NPN Selection function is not available for the F3SG-RE. Select an F3SG-RE of your preferred I/O type.
2-5-2. Factory Default Setting
The factory default setting is PNP type.
2-5-3. Setting with DIP Switch
The user can select the type from PNP or NPN by the DIP Switch.
Refer to Chapter 3 Setting with DIP Switch for more information on setting this function by the DIP Switch.
2-5-4. Setting with Configuration Tool
The user cannot make any changes to the PNP/NPN selection by the Configuration Tool.
F3SG-RA Series X
F3SG-RE Series

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
