Omron F3SG series User Manual

166
Chapter4 Wiring
F3SG-R
User’s Manual
Wiring/Installation
<Internal wiring diagram> (F39-JGA-L)
<Internal wiring diagram> (F39-JGA-D)
4-5-3-2. Double-Ended Cable
 Double-Ended Cable for Emitter: Cable for extension (F39-JGB-L, sold separately)
 Double-Ended Cable for Receiver: Cable for extension (F39-JGB-D, sold separately)
Brown
Black
Blue
White
Yellow
Brown
Black
Blue
White
Yellow
1
2
3
4
5
5
3
21
4
Connect to Power Cable
or Double-Ended Cable
+24 VDC
TEST
0 VDC
Not used
Not used
1
2
3
4
5
Female
5
8
4
3
2
1
7
6
Female
Brown
Blue
Black
White
Yellow
Red
Gray
Pink
Brown
Blue
Black
White
Yellow
Red
Gray
Pink
2
7
5
6
1
8
3
4
+24 VDC
0 VDC
OSSD 1
OSSD 2
RESET
AUX
MUTE A
MUTE B
2
7
5
6
1
8
3
4
M12 IP67 connector
Insulated vinyl round cable dia. 6.6, 5-wire (2-pair + 1)
(Cross section of conductor: 0.38 mm
2
/insulator diameter: dia. 1.2 mm)
(Unit: mm)
M12 IP67 connector
40.7
L
44.7
dia.14.9
dia.14.9
M12 IP67 connector
Insulated vinyl round cable dia. 6.6, 8-wire (4-pair)
(Cross section of conductor: 0.38 mm
2
/insulator diameter: dia. 1.2 mm)
(Unit: mm)
M12 IP67 connector
40.7
L
44.7
dia.14.9
dia.14.9

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
