F3SG-R
User’s Manual
Chapter3 Setting by Teach-in
Setting with DIP Switch
E
3-3-2. Setting Floating Blanking by Teach-in
 Overview
You can teach-in the floating blanking setting by interrupting with an object to monitor by floating
blanking. The teach-in task is performed using the Push Switch.
After completion of teach-in, check that the configuration have been properly done.
 Teach-In Steps
Perform the teach-in setting of floating blanking based on the following steps.
(1) Beam Adjustment
(2) DIP Switch Setting
(3) Transition to Teach-in Mode
(4) Result Check Process
(5) Restart
(1) Beam Adjustment
Adjust the beams of the emitter and receiver for synchronization.
For detailed beam adjustment steps, see 4-4-4. Beam Alignment Procedure.
Misalignment during teach-in may result in an unintended setting or a failure of teach-in.
(2) DIP Switch Setting
When the power of the F3SG-RA is turned OFF, set the Blanking setting (Position 5 and 6) of the DIP
Switch as "Floating Blanking Enabled" and the DIP Switch/Configuration Tool Selection setting
(Position 8) as "DIP Switch Enabled". And then turn the power of the F3SG-RA on.
Block the target Floating Blanking zone by an object. Do not remove the object until the Step (4) is
complete.
The object must be no smaller than the object resolution.
Rfer to 3-2-1. DIP Switch on Receiver for more information.

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
