2-23. Light Level Monitoring
2-23-1. Incident Light Level Information
2-23-1-1. Overview
The user can use the Configuration Tool to read incident light level of the F3SG-RA and view on a PC
screen. This function allows beam adjustment while checking receiving light intensity.
The Light Level Monitoring is not available for the F3SG-RE.
2-23-1-2. Setting with Configuration Tool
The user can enable this function to retrieve incident light level information. Making any changes to the
function is not possible. (When the F3SG-RA is in the cascade connection, incident light level of each
segment can be retrieved.)
2-23-2. Ambient Light Level Information
2-23-2-1. Overview
The user can use the Configuration Tool to read incident light level of ambient light from a photoelectric
sensor or another F3SG-RA unit in a close area and view it on a PC screen. This function allows the
user to identify a photoelectric sensor radiating ambient light or beams being affected by the light.
2-23-2-2. Setting with Configuration Tool
The user can enable this function to retrieve ambient light level information. Making any changes to the
function is not possible. (When the F3SG-RA is in the cascade connection, ambient light level of each
segment can be retrieved.)
Make sure the Position 8 of the DIP Switch is set to Configuration Tool Enabled to activate the settings by the
Configuration Tool.
Refer to Safety Light Curtain Configuration Tool for Model F3SG (SD Manager 2) User’s Manual for more
information?on setting this function by the Configuration Tool.
