Omron F3SG series User Manual

xv
F3SG-R
User’s Manual
Introduction
E
Table of Contents
Legislation and Standards i
Terms and Conditions Agreement iii
Safety Precautions v
Precautions for Safe Use xi
Precautions for Correct Use xii
Visual Aids xiii
Chapter1 Overview and Specifications 1
1-1. What is Included 2
1-2. System Components 3
1-2-1. Basic Components 4
1-2-2. Model Overview 5
1-3. List of Features 6
1-3-1. Model Overview 6
1-3-2. Versions 6
1-3-3. List of Features 7
1-4. LED Indicators 8
1-4-1. LED Indicator Status 9
1-5. Ratings/Specifications 11
1-6. List of Models 15
1-6-1. List of Models/Response Time/Current Consumption/Weight 15
1-6-2. Calculation of Response Time of Cascaded Segments 18
Chapter2 System Operation and Functions 19
2-1. Combination of Functions 21
2-2. Operating States 23
2-2-1. Machine Run State 23
2-2-2. Machine Stop State 23
2-2-3. Interlock State 23
2-2-4. Lockout State 23
2-2-5. Teach-in Mode 23
2-2-6. Setting State 24
2-3. Optical Synchronization 25
2-3-1. Overview 25
2-4. Scan Code Selection 26
2-4-1. Overview 26
2-4-2. Factory Default Setting 26
2-4-3. Setting with DIP Switch 26
2-4-4. Setting with Configuration Tool 26

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
