Omron F3SG series User Manual

9
F3SG-R
User’s Manual
Chapter1 LED Indicators
Overview and Specifications
E
1-4-1. LED Indicator Status
Shown below are indication statuses of F3SG-R LED indicators when you purchased.
Emitter
Receiver
Location Name of Indicator Color
F3SG-RA
Series
F3SG-RE
Series
Illuminated Blinking
1 Test TEST Green X -
External Test is being
performed
2 Operating range LONG Green X X
Long range mode is
selected
Lockout state due to DIP
Switch setting error or
Operating range selection
setting error
3 Power POWER Green X X Power is ON. Error due to noise
4 Lockout LOCKOUT Red X X -
Lockout state due to error
in emitter
Location Name of Indicator Color
F3SG-RA
Series
F3SG-RE
Series
Illuminated Blinking
1 Top-beam-state TOP Blue X X
The top beam is
unblocked
Muting/Override state, or
Lockout state due to Cap
error or Other sensor error
*3
2 PNP/NPN mode NPN Green X
NPN mode is selected by
DIP Switch
-
3 Response time SLOW Green X
Response Time
Adjustment is enabled
-
4 Sequence error SEQ Yellow X -
Sequence error in Muting
or Pre-reset mode
5 Blanking BLANK Green X
Blanking, Warning Zone
or Reduced Resolution is
enabled
Teach-in mode, or
Blanking Monitoring error
6 Configuration CFG Green X -
Teach-in mode, zone
measurement beng
performed by Dynamic
Muting, or Lockout state
due to Parameter error or
Cascading Configuration
error
7 Interlock INT-LK Yellow X Interlock state Pre-reset mode *2
8
External device
monitoring
EDM Green X
RESET input is in ON
state *1
Lockout state due to EDM
error
9 Internal error
INTERNAL Red X X -
Lockout state due to
Internal error, or error due
to abnormal power supply
or noise
10 Lockout LOCKOUT Red X X -
Lockout state due to error
in receiver
11 Stable-state STB Green X X
Incident light level is
170% or higher of ON-
threshold
Safety output is
instantaneously turned
OFF due to ambient light
or vibration
12 ON/OFF ON/OFF
Green
XX
Safety output is in ON
state
-
Red
Safety output is in OFF
state, or the sensor is in
Setting state
Lockout state due to
Safety Output error, or
error due to abnormal
power supply or noise

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
