Omron F3SG series User Manual

153
F3SG-R
User’s Manual
Chapter4 Mounting
Wiring/Installation
E
4-4. Mounting
4-4-1. Mounting Method
You can mount the F3SG-R with Standard Fixed Brackets and Standard Adjustable Brackets. Any of
these mounting methods allows the user to use the same bracket for the backside mounting and side
mounting.
4-4-2. Number of Brackets Required
The numbers of brackets required according to the protective heights of the sensor are as follows:
• Mounting with Standard Fixed Brackets Only
• Mounting with Standard Adjustable Brackets Only
• Mounting with Top/Bottom Adjustable Brackets and Standard Adjustable Brackets
* The number of brackets required to mount either one of emitter and receiver.
Make sure that the F3SG-R is securely mounted and its cables and connectors are properly connected.
The required number of brackets is the same between F3SG-RA and F3SG-RE series.
Protective height
Number of Standard Fixed
Brackets*
F3SG-R30 F3SG-R14
0190 to 1230 0160 to 1200 2
1310 to 2270 1280 to 2080 3
2350 to 2510 - 4
Protective height
Number of Standard
Adjustable Brackets*
F3SG-R30 F3SG-R14
0190 to 1230 0160 to 1200 2
1310 to 2270 1280 to 2080 3
2350 to 2510 - 4
Protective height
Number of Top/Bottom
Adjustable Brackets*
Number of Standard
Adjustable Brackets*
F3SG-R30 F3SG-R14
0190 to 1070 0160 to 1040 2 0
1150 to 1950 1120 to 1920 2 1
2030 to 2510 2000 to 2080 2 2

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
