24
Chapter2 Operating States
F3SG-R
User’s Manual
System Operation and Functions
2-2-6. Setting State
The two receiver safety outputs are in the OFF state, the green Power indicator of the emitter is
blinking. The blue Top-beam-state indicator, green Configuration indicator, red Lockout indicator, green
Stable-state indicator and green ON/OFF indicator of the receiver are blinking. The Setting state does
not allow the protected machine to operate. The user can change settings of the functions, monitor the
operating states or view maintenance information with the Configuration Tool (SD Manager 2) under
this state.
The F3SG-RE does not have the Setting state.
Refer to Safety Light Curtain Configuration Tool for Model F3SG (SD Manager 2) User’s Manual for more
information.

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
